| 订货代码 |
结构 芯数×截面积 （mm²） |
标称绝缘厚度 mm |
标称护套厚度 mm |
标称外径 mm |
标称重量 kg/km |
|---|---|---|---|---|---|
| MFX400-1mRZ1-R-2C1.5 | 2×1.5 | 0.7 | 1.1 | 8.5 | 85 |
| MFX400-1mRZ1-R-2C2.5 | 2×2.5 | 0.7 | 1.1 | 9.5 | 110 |
| MFX400-1mRZ1-R-2C4 | 2×4 | 0.9 | 1.1 | 11.7 | 140 |
| MFX400-1mRZ1-R-2C6 | 2×6 | 0.9 | 1.2 | 13.0 | 230 |
| MFX400-1mRZ1-R-2C10 | 2×10 | 0.9 | 1.2 | 14.7 | 330 |
| MFX400-1mRZ1-R-2C16 | 2×16 | 0.9 | 1.3 | 17.0 | 490 |
| MFX400-1mRZ1-R-2C25 | 2×25 | 0.9 | 1.3 | 19.5 | 750 |
| MFX400-1mRZ1-R-2C35 | 2×35 | 0.9 | 1.5 | 22.0 | 990 |
| MFX400-1mRZ1-R-2C50 | 2×50 | 1.0 | 1.5 | 24.8 | 1340 |
| MFX400-1mRZ1-R-3C1.5 | 3×1.5 | 0.7 | 1.1 | 9.5 | 105 |
| MFX400-1mRZ1-R-3C2.5 | 3×2.5 | 0.7 | 1.1 | 10.0 | 145 |
| MFX400-1mRZ1-R-3C4 | 3×4 | 0.9 | 1.2 | 12.7 | 205 |
| MFX400-1mRZ1-R-3C6 | 3×6 | 0.9 | 1.2 | 13.9 | 270 |
| MFX400-1mRZ1-R-3C10 | 3×10 | 0.9 | 1.3 | 15.9 | 400 |
| MFX400-1mRZ1-R-3C16 | 3×16 | 0.9 | 1.3 | 18.4 | 610 |
| MFX400-1mRZ1-R-3C25 | 3×25 | 0.9 | 1.5 | 21.4 | 920 |
| MFX400-1mRZ1-R-3C35 | 3×35 | 0.9 | 1.6 | 24.2 | 1330 |
| MFX400-1mRZ1-R-3C50 | 3×50 | 1.0 | 1.7 | 27.5 | 1830 |
| MFX400-1mRZ1-R-3C70 | 3×70 | 1.1 | 1.8 | 32.0 | 2570 |
| MFX400-1mRZ1-R-3C70S | 3×70 (sector shaped) | 1.1 | 1.8 | 27.5 | 2370 |
| MFX400-1mRZ1-R-3C95 | 3×95 | 1.1 | 1.9 | 36.4 | 3360 |
| MFX400-1mRZ1-R-3C95S | 3×95 (sector shaped) | 1.1 | 1.9 | 31.1 | 3130 |
| MFX400-1mRZ1-R-3C120 | 3×120 | 1.2 | 2.1 | 40.7 | 4180 |
| MFX400-1mRZ1-R-3C120S | 3×120 (sector shaped) | 1.2 | 2.1 | 34.4 | 3930 |
| MFX400-1mRZ1-R-4C1.5 | 4×1.5 | 0.7 | 1.1 | 10.0 | 135 |
| MFX400-1mRZ1-R-4C2.5 | 4×2.5 | 0.7 | 1.1 | 11.2 | 180 |
| MFX400-1mRZ1-R-4C4 | 4×4 | 0.9 | 1.2 | 13.9 | 260 |
| MFX400-1mRZ1-R-4C6 | 4×6 | 0.9 | 1.2 | 15.2 | 350 |
| MFX400-1mRZ1-R-4C10 | 4×10 | 0.9 | 1.3 | 17.4 | 530 |
| MFX400-1mRZ1-R-4C16 | 4×16 | 0.9 | 1.4 | 20.2 | 800 |
| MFX400-1mRZ1-R-4C25 | 4×25 | 0.9 | 1.5 | 23.5 | 1230 |
| MFX400-1mRZ1-R-4C35 | 4×35 | 0.9 | 1.7 | 26.7 | 1650 |
| MFX400-1mRZ1-R-5C1.5 | 5×1.5 | 0.7 | 1.1 | 11.0 | 170 |
| MFX400-1mRZ1-R-7C1.5 | 7×1.5 | 0.7 | 1.2 | 12.6 | 210 |
| MFX400-1mRZ1-R-12C1.5 | 12×1.5 | 0.7 | 1.3 | 16.5 | 350 |
| MFX400-1mRZ1-R-19C1.5 | 19×1.5 | 0.7 | 1.4 | 19.6 | 520 |
| MFX400-1mRZ1-R-27C1.5 | 27×1.5 | 0.7 | 1.5 | 23.3 | 730 |
| MFX400-1mRZ1-R-37C1.5 | 37×1.5 | 0.7 | 1.6 | 26.3 | 980 |
| MFX400-1mRZ1-R-5C2.5 | 5×2.5 | 0.7 | 1.2 | 12.5 | 240 |
| MFX400-1mRZ1-R-7C2.5 | 7×2.5 | 0.7 | 1.2 | 14.1 | 300 |
| MFX400-1mRZ1-R-12C2.5 | 12×2.5 | 0.7 | 1.3 | 18.6 | 490 |
| MFX400-1mRZ1-R-19C2.5 | 19×2.5 | 0.7 | 1.4 | 22.1 | 750 |
| MFX400-1mRZ1-R-27C2.5 | 27×2.5 | 0.7 | 1.5 | 26.4 | 1060 |
